LC248EL0 04 – DRYER MOTOR, BLOWER AND BELT

LC248EL0 04 – DRYER MOTOR, BLOWER AND BELT

Written by

in

LC248EL0 04 – DRYER MOTOR, BLOWER AND BELT

Products

Position	Product
*83260	WCI 8027675
1	WCI 8015833
2	WCI 1128554
3	WCI 8015787
4	WCI 0639342
5	WCI 8015796
6	WCI 0639383
7	WCI 0639357
8	WCI 8015834
9	WCI 8006556
10	WCI 8015793
11	WCI 8014798
13	WCI 8015848
14	WCI 8001650
15	WCI 8002293
16	WCI 8015846
20	WCI 8011280
21	BRKT-THERMO MTG
22	WCI 5436685
23	WCI 0633925
25	WCI 8015823
26	WCI 8015828
27	WCI 8015824
28	WCI 8015797
29	WCI 8015847
29A	WCI 8008892
30	WCI 1127285
31	WCI 8004087
32	WCI 8001558
33	SCREW-BAFFLE/DRUM (6)
34	WCI 8027503
35	WCI 8002468
35A	WCI 8001557
36	SCREW (6)
37	WCI 8015799
38	WCI 8001572
40	WCI 8006548
41	WCI 8004112
42	WCI 8004113
42A	SCREW (4)
43	WCI 8001570
44	WCI 8001569
45	WCI 8006557
46	SCREW (4)
47	WCI 8011257
48	BRACE (2)
49	WCI 8006559
50	PLATE (2)
51	BLOCK
52	WCI 8027674
53	WCI 8001676
54	WCI 8004061
56	WCI 8002341
