LC400RXD3 07 – PORTABLE WASHER COMPONENTS

Products

Position	Product
1	WCI 5303284143
2	WCI 5303283875
3	CASTER-FRONT (2)
4A	5303015671 Frigidaire Bracket Termination Screw
4	SCREW-CASTER (4)
5	WCI 08027587
6	SPEEDNUT
7	WCI 5303283876
8	SPRING
9	WCI 08027591
11	WCI 08027592
12	WCI 08027593
13	WCI 08027594
14	WCI 08027595
15	WCI 08037851
16	WCI 08027597
17	SPRING WASHER
18	WCI 5308002468
19	SCREW
20	WCI 08027598
21	WCI 08027599
