LC550LXD0 06 – CONSOLE AND CONTROL PARTS

Products

Position	Product
1	WCI F140485000
2	134154100 Frigidaire Screw 10-32 x 0.375 Co
3	WCI F08008454
4	WCI Q000199015
5	WCI 3015649
6	WCI 3018392
7	WCI F131347000
9	WCI F060796000
11	WCI F000139096
12	WCI Q000199081
13	WCI Q000199019
14	WCI Q000199020
16	WCI F078949000
19	SWITCH-WATER TEMP
19A	WCI 3018800
20	WCI 3016450
22	131243800 Frigidaire Screw
23	WCI 3017110
24	WCI F141175000
25	134190200 Frigidaire Washer Water Valve
25B	WCI F076138-11
25A	WCI F076138-15
26	5303912532 Frigidaire Hose Inlet 60"
27	WCI F139814000
31	WCI F135021000
32	WCI F000077094
33A	SCREW-SUPPORT/LH SIDE PNL
33	218359202 Frigidaire Refrigerator Screw
34	BRACKET-LID LOCK & SW ASSEMBLY
