LC590LXD0 05 – TUBS AND WATER INLET

Products

Position	Product
1	WCI F142025-000
2	SEAL-TUB COVER
3	WCI 3161199
4	WCI 08027519
7	WCI 3161486
8	137539500 Frigidaire Washer Trunnion Lock Plate Bolt
9	137107000 Frigidaire Plate
10	WCI 08014908
11	WCI 3161127
12	WCI 08027536
15	WCI 08006573
16	WCI F130789-000
17	WCI 3161284
18	BLOCK-SHIPPING
19	NUT-EXPANSION
20	SPRING-VERTICAL-SHORT
21	WCI 3161485
22	LEG & DOME
23	WCI F073565-000
24	CAP-AGITATOR (INCL 9)
25	WCI 3161204
26	SCREW (6)
27	SPRING-VERTICAL-LONG
29	WCI 3161207
30	WCI 08006571
31	WCI 3161206
34	WCI 08027515
37	5308002401 Frigidaire Washer Primary
38	WCI 3161134
40	WCI F139128000
44	WCI 08006564
