LDE27CD 01 – FRONT VIEW

Products

Position	Product
001	MAY 306398
002	WP3177991 Whirlpool Screw
002	MAY 901961
003	MAY 314627
007	MAY 212982
008	MAY Y310376
009	TOP COVER ASSY. (WHT)
010	MAY Y313559
011	213007 Whirlpool Screw #12
011	MAY 204445
012	MAY 306261
012	MAY 314663
013	MAY 310933
014	MAY Y310632
016	LEG, ADJUSTABLE (W/NUT)—S
017	WP210684 Whirlpool Dishwasher Leveling Leg Pad
018	WP210385 Whirlpool Lock Nut
020	SCREW & FSTNER ASSY (FT. PNL)
022	MAY 314522
024	MAY 314967
024	DOWEL PIN FOR HANDLE
025	MAY 308069
026	MAY 314974
026	MAY 314975
026	MAY 314939
