LE5800XKW1 03 – SECTION

Products

Position	Product
	Almond (Uncut)
	Enamel, New Avocado (1 Qt. Uncut)
	799344 Whirlpool Refrigerator Paint
	Golden Harvest (Uncut)
1	Panel, Rear Console
2	SCREW
3	WPL 355326
4	Cap, End (L.H.) (Golden Harvest Cap, End (R.H.))
4	End Cap Assembly, L.H. (New Avocado)
4	End Cap Assembly, L.H. (New Avocado)
4	Cap, End (L.H.) (White)
4	Cap, End L.H. (Almond Cap, End R.H.)
4	Cap, End (L.H.) (Almond)
4	Cap, End L.H. (Golden Harvest)
4	Cap, End L.H. (White)
5	279872 Whirlpool Resistor
6	Stop, Push-In Top
7	Clip
8	Nut, Push-In (2)
10	339392V Whirlpool Dryer Lint Filter Screen
11	Cover, Lint Screen (Almond)
11	Cover, Lint Screen (Golden Harvest)
11	Cover, Lint Screen (New Avocado)
11	Cover, Lint Screen (White)
12	WPW10044480 Whirlpool Hinge Assembly
12	WPW10044470 Whirlpool Hinge Assembly
13	W11693756 Whirlpool Screw Assembly
14	Screw, 8-18 x 1 (2)
16	top (white)
16	Top (New Avocado)
16	Top (Almond)
16	Top (Golden Harvest)
18	Control Knob Assembly
21	Timer & Resistor Assembly, 60 Hz.
29	WP3390631 Whirlpool Screw
31	Harness, Wiring
39	Switch, Push-To-Start
48	Timer Knob Assembly
53	Bracket, Control
54	Panel, Control
62	WP688805 Whirlpool Spring Clip
67	WP689559 Whirlpool Nut
72	Wire, Ground
76	Buzzer, Mini
79	Switch, Temperature Selector
81	Button Assembly
83	WPL 690724
83	WPL 688898
83	WPL 693363
83	WPL 688643
83	350956 Whirlpool Spray Assembly
83	72017 Whirlpool Appliance Touch-Up Paint White
83	WP72107 Whirlpool Touchup
83	Leveler (Thinner)
83	72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
83	Golden Harvest
83	Paint, Spray 13 Oz. (Avocado)
83	WPL 799351
83	Rack, Literature
83	350930 Whirlpool White Spray Paint
83	72109 Whirlpool Dacor Avocado Touch-Up Paint
83	350938 Whirlpool Spray Gun
