LER3622DZ1 03 – SECTION

Products

Position	Product
1	Top (Almond)
1	345703 Whirlpool White Maintop
2	Rivet, Plastic (4)
3	WP3390631 Whirlpool Screw
8	WP688805 Whirlpool Spring Clip
20	WP8563882 Whirlpool Timer Assembly
21	(Timer Motor Not Serviceable)
22	348171 Whirlpool Bracket
23	303776 Whirlpool Dishwasher Screw
29	WPW10139210 Whirlpool Screw
31	Panel, Control (Almond)
31	Panel, Control (White)
32	Timer Knob & Dial (White)
32	Timer Knob & Dial (Almond)
36	Switch, Push-To-Start
37	WP3957800 Whirlpool Knob
51	SCREW
