LHE5700W0 03 – SECTION

Products

Position	Product
	Golden Harvest (Uncut)
	Enamel, New Avocado (1 Qt. Uncut)
	Enamel, Coffee (1 Qt. Uncut)
	799344 Whirlpool Refrigerator Paint
	Almond (Uncut)
1	Panel, Rear
2	SCREW
3	WPL 355326
4	Cap, End L.H. (White)
4	End Cap Assembly, L.H. (New Avocado)
4	End Cap Assembly, L.H. (Coffee)
4	End Cap Assembly, L.H. (Coffee)
4	Cap, End (L.H.) (Golden Harvest Cap, End (R.H.))
4	Cap, End (L.H.) (Almond)
4	Cap, End L.H. (Golden Harvest)
4	Cap, End L.H. (Almond Cap, End R.H.)
4	Cap, End (L.H.) (White)
4	End Cap Assembly, L.H. (New Avocado)
5	Stop, Push-In Top
6	Screw, 8-18 x 1 (2)
7	Clip
10	339392V Whirlpool Dryer Lint Filter Screen
11	Cover, Lint Screen (New Avocado)
11	Cover, Lint Screen (Almond)
11	Cover, Lint Screen (White)
11	Cover, Lint Screen (Golden Harvest)
11	Cover, Lint Screen (Coffee)
12	WPW10044480 Whirlpool Hinge Assembly
12	WPW10044470 Whirlpool Hinge Assembly
13	W11693756 Whirlpool Screw Assembly
16	Top (Golden Harvest)
16	Top (Coffee)
16	Top (Almond)
16	top (white)
16	Top (New Avocado)
18	Control Knob Assembly
21	Timer, 50 Hz. (Use W/Model 3LE5700XKW0)
21	Timer, 60 Hz.
22	Motor, 60 Hz. (Use W/687950 Timer)
22	Motor, 50 Hz/60 Hz.
29	WP3390631 Whirlpool Screw
30	Nut, Push-In (2)
39	Switch, Push-To-Start (Alternate)
48	Timer Knob Assembly
53	Bracket, Control
54	Panel, Control
62	WP688805 Whirlpool Spring Clip
67	WP689559 Whirlpool Nut
72	Wire, Ground
79	Switch, Rotary
81	Button Assembly
83	Rack, Literature
84	72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
84	WPL 688786
84	Leveler (Thinner)
84	WPL 799351
84	350938 Whirlpool Spray Gun
84	WPL 687858
84	WP72107 Whirlpool Touchup
84	72017 Whirlpool Appliance Touch-Up Paint White
84	350956 Whirlpool Spray Assembly
84	Golden Harvest
84	350930 Whirlpool White Spray Paint
84	WPL 685870
84	Supplement, Installation Instructions
84	Instructions, Harness Rework
84	Instructions, Wiring
84	WPL 688643
84	WPL 688898
84	WPL 690002
84	W10851673 Whirlpool Transformer
84	Harness, Wiring (50 Hz.) (Use W/Model 3LE5700XKW0)
84	Paint, Spray 13 Oz. (Avocado)
84	paint, spray 13 oz. (coffee)
84	Paint, Touch-Up 1/2 Oz. (Coffee)
84	72109 Whirlpool Dacor Avocado Touch-Up Paint
84	WPL 690383
