LHE9800W0 02 – SECTION

LHE9800W0 02 – SECTION

Written by

in

LHE9800W0 02 – SECTION

Products

Position	Product
	Golden Harvest (Uncut)
	Wire, 25` Roll (Red 12 Ga.)
	Enamel, Coffee (1 Qt. Uncut)
	WPL 010875
	Enamel, New Avocado (1 Qt. Uncut)
	799344 Whirlpool Refrigerator Paint
	Almond (Uncut)
1	Panel, Rear Console
2	Panel, Control
3	WPL 355326
4	End Cap Assembly, L.H. (Coffee)
4	End Cap Assembly, L.H. (New Avocado)
4	Cap, End (L.H.) (White)
4	Cap, End L.H. (Almond Cap, End R.H.)
4	End Cap Assembly, L.H. (Coffee)
4	Cap, End (L.H.) (Golden Harvest Cap, End (R.H.))
4	Cap, End (L.H.) (Almond)
4	Cap, End L.H. (Golden Harvest)
4	End Cap Assembly, L.H. (New Avocado)
4	Cap, End L.H. (White)
5	Rack, Literature
6	SCREW
7	Bracket, Control
8	Trim, Frame
9	Pivot, Lever
10	WP349639 Whirlpool Lint Filter
11	Cover, Lint Screen (Coffee)
11	Cover, Lint Screen (New Avocado)
11	Cover, Lint Screen (Golden Harvest)
11	Cover, Lint Screen (Almond)
11	Cover, Lint Screen (White)
12	WPW10044470 Whirlpool Hinge Assembly
12	WPW10044480 Whirlpool Hinge Assembly
13	W11693756 Whirlpool Screw Assembly
14	WPW10339879 Whirlpool Wire Tie
15	Lever
16	Top (Almond)
16	top (white)
16	Top (New Avocado)
16	Top (Coffee)
16	Top (Golden Harvest)
17	Transformer
18	Screw, 8-18 x 1 (2)
19	Stop, Push-In Top
20	Module, Touch
21	Display Assembly
22	Harness, Display
23	Relay, Push-To-Start
24	Screw, 8-18 x 1/2 (6)
26	Microcomputer Assembly
28	Speaker & Harness Assembly
29	Wire, Ground
30	Nut, Push-In (2)
31	WP689559 Whirlpool Nut
32	WPW10068250 Whirlpool Dishwasher Screw
33	Plug
34	WPL 60447
35	WPL 60719
36	WP94614 Whirlpool Terminal
36	WP596797 Whirlpool Terminal
37	Terminal
39	Clip, Wire (Tech Sheet/Top)
40	WPL 359188
41	350956 Whirlpool Spray Assembly
41	350938 Whirlpool Spray Gun
41	Supplement, Installation Instructions
41	WPL 687853
41	WPL 689029
41	WPL 689598
41	WPL 690072
41	72017 Whirlpool Appliance Touch-Up Paint White
41	WP72107 Whirlpool Touchup
41	Leveler (Thinner)
41	Instructions, Wiring
41	W10851673 Whirlpool Transformer
41	Instructions, Harness Rework
41	WPL 688643
41	WPL 688898
41	WPL 799351
41	Paint, Spray 13 Oz. (Avocado)
41	paint, spray 13 oz. (coffee)
41	Paint, Touch-Up 1/2 Oz. (Coffee)
41	72109 Whirlpool Dacor Avocado Touch-Up Paint
41	350930 Whirlpool White Spray Paint
41	Golden Harvest
41	72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
41	WPL 60671
