M166W 04 – INTERNAL CONTROLS (M166)

M166W 04 – INTERNAL CONTROLS (M166)

Written by

in

M166W 04 – INTERNAL CONTROLS (M166)

Products

Position	Product
1	BRACKET, INTERLOCK
2	SWITCH, SECONDARY INTERLOCK
3	MAY Y01140030
3	MAY Y01140038
3	SWITCH, MONITOR INTERLOCK
4	MAY 01140068
4	MAY Y01140042
4	SWITCH, PRIMARY INTERLOCK
5	MAY Y01140043
5	SWITCH, LOGIC INTERLOCK
6	MAY Y01100043
6	INSULATOR, SWITCH
7	NUT
7	MAY Y03050001
8	MAY 03050003
8	NUT
9	CLIP-RETAINER
9	MAY 03110040
10	LATCH, DOOR INTERLOCK
10	MAY 02190049
11	PIN, LEVER & PIVOT LATCH
11	MAY Y03070031
12	SCREW
12	MAY 03010114
13	MAY 03010131
13	SCREW
14	MAY 01130028
14	TRANSFORMER
15	PLATE, COMPONENT MOUNTING
15	MAY 02040053
16	MAY 01080050
16	CORD-POWER
17	MAY 03020092
17	SCREW
18	MAY Y02230008
18	FOOT-BASE
19	SCREW
19	MAY Y03020068
20	MAY 03010094
20	SCREW
