MAF18MC1 08 – SOAP DISPENSER – Aparts

MAF18MC1 08 – SOAP DISPENSER

Products

Position	Product
001	DISPENSER, SUPPLY (COIN)
002	MAY 24001031
003	MAY 24001032
004	VALVE (2WAY 110-127V/50-60HZ)
005	VALVE (3WAY 110-127V/50-60HZ)
006	MAY 24001765
007	MAY 24001766
008	MAY 24001433
009	MAY 24001225
011	MAY 24001301
012	BLOCK, INPUT POWER (3 WIRE)
013	MAY 24001430
014	COVER, JUNCTION BOX
015	MAY 24001436
016	MAY 24001434
017	MAY 24001342
018	MAY 24001767
019	MAY 24001768
020	MAY 24001769
021	MAY 24001770
022	MAY 24001771
023	MAY 24001772
024	MAY 24001773
025	DOWEL PIN FOR HANDLE
026	MAY 24001432
027	MAY 24001426
028	MAY 24001552
029	MAY 24001442
030	MAY 24001353
031	MAY 24001282
032	MAY 24001423
033	MAY 24001357
034	MAY 24001414
035	MAY 24001425
036	MAY 24001424
037	MAY 24001775
