MBF2258XEB3 01 – CABINET PARTS

Products

PositionProduct
1MAY W10366206SP
1MAY W10325962
1MAY W10475386
2LINER (NOT A SERVICEABLE PART)
4MAY B5759655
5GUARD-WATER VALVE
6Brake, Foot
7MAY 10351006
8MAY W10216614
9MAY 12992602
10COVER, HINGE(BLACK)
10MAY 12477601W
11MAY 12990101
12Screw (8)
13MAY 12726003
14SCREW (6)
15MAY 12607104ED
15MAY 12607103WD
16MAY 12566606ED
17COVER, CORNER (BLACK)
17Cover, Corner (2) (White)
19ROLLER ASSY. (FRONT) (LEFT)
19ROLLER ASSY. (FRONT) (RIGHT)
20Screw (8)
21MAY W10210979
22GRILLE ASSEMBLY (INCLUDES CLIPS) (WHITE)
22GRILLE ASSEMBLY (INCLUDES CLIPS) (BLACK)
24MAY W10210988
25SCREW (10)
26Insulation, Sound
30MAY 12990504
