MEF350SFDB 03 – BODY

MEF350SFDB 03 – BODY

Written by

in

MEF350SFDB 03 – BODY

Products

PositionProduct
*63527Screw,cup pt ,8-18 x 0.375 ,chrome
*635295308014215 Frigidaire Oven Screw
*635263203550 Frigidaire Oven Plug
*63528316205500 Frigidaire Oven Nut
*63530PANEL-BODYSIDE,ALMOND ,LH
*63531WCI 3934058
*63532316116000 Frigidaire Screw
1WCI 316080804
3WCI 316081030
4WCI 5303271756
5NUT, T,TYPE, LEVELING SCREW (NOT ILLUSTRATED)
5SCREW-LEVELING
6316067902 Frigidaire Oven Rack
7HINGE-OVEN DOOR,ASSEMBLY
8PANEL-OVEN BOTTOM
9WCI 316073800
10WCI 3205234
12WCI 316027700
18WCI 316036300
21SPACER-BODYSIDE, (8)
25WCI 3200848
293051162 Frigidaire Oven Range Front Broiler Drawer Glide
30BRACKET-HINGE, MAIN TOP RH
30BRACKET-HINGE, MAIN TOP, LH
375304497424 Frigidaire Oven Temperature Sensor Probe Kit
41WCI 3131570
443131903 Frigidaire Door/Drawer Bumper
57WCI 316081101
58316403803 Frigidaire Insulation
58316047707 Frigidaire Insulation
58INSULATION, OVEN WRAPPER
58316054202 Frigidaire Insulation
58WCI 316054200
59WCI 316073600
60316021105 Frigidaire Oven Screw
625304409888 Frigidaire Oven Terminal Block with Hardware
63PLATE=GROUND STRAP
665303051140 Frigidaire Broil Element
67316075103 Frigidaire Oven Bake Element
68316203400 Frigidaire Oven Support
693051218 Frigidaire Oven Plate
71WCI 316015805
82WCI 5303289913
87316081200 Frigidaire Oven Bracket
88WCI 316026400
89WCI 316028101
