MER6765BAW 02 – CONTROL PANEL/TOP ASSEMBLY

Products

Position	Product
1	MAY 2602D345-81
2	BRACKET, CLOCK
3	W10769079-includeCORE Whirlpool W10769079 Refrigerator Electronic Control Board + Core
4	WP74004153 Whirlpool Indicator Light
5	WP7730P011-60 Whirlpool Indicator Lens
6	WP74003122 Whirlpool Infinite Switch Assembly (Dual)
6	WP7403P239-60 Whirlpool Oven Switch
6	WP7403P238-60 Whirlpool Infinite Switch (Small Element)
7	WP74010226 Whirlpool RO Switch
8	MAY 74010713
8	WP74003976 Whirlpool Screw
8	WP98008544 Whirlpool Screw Assembly
8	MAY 74010212
9	MAY 74009978
10	SCREW (8BX3/8-NI)
10	MAY 74010804
11	WP74008947 Whirlpool Knob White
12	MAY 5706X615-81
13	SCREW
14	SCREW
15	W10823715 Whirlpool Radiant Surface Element
16	W10823711 Whirlpool Surface Element Left Front and Right Rear
17	W10823713 Whirlpool Surface Element
18	ELEMENT (CTR)
18	WP74009899 Whirlpool Element
19	8004P093-60 Whirlpool Support C
20	W11189172 Whirlpool Glide Drawer
21	MAY 74009701
22	MAY 7728P493-60
