MGDE400XR1 02 – CABINET PARTS

Products

Position	Product
NI	DRYER EXHAUST KIT (FOR SIDE & BOTTOMVENTING) (MIDNIGHT GREY)
NI	MAY 279818
NI	MAY 279810
1	MAY 8317340
2	Screw, 8-18 x 3/8
3	MAY 8533974
4	Panel, Side (R.H.) (White)
4	MAY W10249769
5	MAY W10246525
6	Panel, Side (L.H.) (White)
6	MAY W10249768
7	MAY 3392100
8	MAY 660658
9	MAY 3387374
10	SCREW
11	MAY W10151499
11	MAY 49252
12	ASSEMBLY, PULLEY
13	MAY 3978776
14	MAY W10123956
17	MAY W10121334
18	SWITCH, ASSEMBLY DOOR
19	WASHER, TRI RING
20	MAY 8066115
21	MAY 8529053
24	MAY W10250900
26	Pulley 60 HZ.
27	MAY W10112954
28	MAY 8529757
29	MAY W10242878
30	MAY 3401401
31	MAY 49026
32	Screw
33	PIPE, EXHAUST (MEDIUM)
34	MAY 8563750
35	PIPE, EXHAUST (LONG)
36	MAY 3388674
37	Clip, S-Type (3)
38	TRIM-RING ASSEMBLY (WHITE)
38	TRIM-RING ASSEMBLY (INCLUDE, ITEM. 48 ) (RED)
40	Screw
41	MAY 3387242
42	SCREW
43	MAY 8519459
44	Trim-Clip Metal
45	MAY W10239098
46	FRONT PANEL (INCLUDES, ITEM. 44 ) (RED)
46	FRONT PANEL (INCLUDES, ITEM. 44 ) (WHITE)
47	MAY 696144
48	SCREW,8-18 X 3/8
49	SCREW
50	MAY W10242903
51	Bracket, Control
52	CONTROL BOARD
54	PANEL, TOE (RED)
54	PANEL, TOE
55	MAY W10303519
56	DAPENING PANEL
