MGR8875WW1 01 – COOKTOP PARTS

MGR8875WW1 01 – COOKTOP PARTS

Written by

in

MGR8875WW1 01 – COOKTOP PARTS

Products

Position	Product
1	TIPS, SAFE COOKING (ENGLISH)
1	MAY W10258096
1	MAY W10239464
1	WIRING DIAGRAM (ENGLISH)
1	WIRING DIAGRAM (FRENCH)
1	TIPS, SAFE COOKING (FRENCH)
2	CAP, BURNER LEFT FRONT (BLACK)
2	CAP, BURNER LEFT FRONT (GREY)
3	MAY 8010P149-60
4	HEAD, BURNER (RF)
4	BURNER (LR/RR/RF)
4	HEAD, BURNER CTR.
4	ORIFICE, BURNER (CENTER)
5	MAY W10237151
5	MAY W10237150
6	MAY W10211395
6	MAY W10211381
6	MAY W10211380
7	MAY W10111302
7	KNOB, BURNER (BLACK)
7	MAY W10200192
8	GRATE, BURNER (WETSTONE)
8	MAY W10225517
9	SCREW
11	SCREW
12	COVER, CAP
13	SET, FISH BURNER CAP (BLACK)
13	SET, FISH BURNER CAP (WETSTONE)
