MGT8885XB02 04 – CHASSIS PARTS
Written by
in
MGT8885XB02 04 – CHASSIS PARTS
Products
Position
Product
NI
MAY W10344586
NI
INSULATION, BACK (LOWER)
NI
INSULATION, WRAPPER (UPPER)
NI
INSULATION, WRAPPER (LOWER)
NI
INSULATION, BACK (UPPER)
1
MAY W10319038
2
MAY W10237689
3
MAY W10267456
4
MAY W10330376
4
MAY W10330375
5
BRACKET, ANTI-TIP
6
MAY W10319000
7
MAY W10284945
8
Leg, Leveling
9
ASSEMBLY, BUMPER
10
SENSOR, OVEN
11
MAY W10268558
12
MAY 7101P635-60
13
MAY W10261387
14
ASSEMBLY, UPPER FLUE
14
MAY W10272519
15
MAY 7101P434-60
16
MAY W10260580
17
ASSEMBLY, OUTLET FLUE (LOWER)
17
ASSEMBLY, OUTLET FLUE (UPPER)
18
MAY 4449040
19
BRACKET, U CHANNEL
20
SCREW, ANTI-TIP KIT
21
MAY W10323374
22
MAY W10299886
23
MAY W10370650
24
MAY W10318928
24
MAY W10269069
25
MAY W10284949
26
SHIELD, SIDE INSULATION
27
Screw (Black) (2)
28
BOTTOM, OVEN GAS
29
MAY W10324643
30
MAY W10260703
31
MAY W10410463
31
MAY W10410461
←
