MLXE42RBD0 03 – MOTOR AND BLOWER PARTS

MLXE42RBD0 03 – MOTOR AND BLOWER PARTS

Written by

in

MLXE42RBD0 03 – MOTOR AND BLOWER PARTS

Products

PositionProduct
*99003131453000 Frigidaire Bushing
1WCI 131151200
4SCREW (2)
65304521121 Frigidaire Duct
73204490 Frigidaire Seal
8SCREW (6)
105304485558 Frigidaire Blower Housing Assembly, Front & Rear
12BLOWER WHEEL
14WCI 5303206879
153204307 Frigidaire Dryer Thermostat Control, L135
16134178901 Frigidaire Screw
17WCI 5303271179
19WCI 3204311
21WCI 3281077
223205241 Frigidaire Idler Spring
23IDLER ARM
25BELT-DRYER LC
26BLOCK-SUPPORT
27WCI 5303212834
28WCI 5303283288
29134037400 Frigidaire Block
30WCI 5308015309
31WCI 5303212832
32WCI 3204317
33134154100 Frigidaire Screw 10-32 x 0.375 Co
34SHIELD-ACCESS
36131243700 Frigidaire Screw
38ELBOW
39131205100 Frigidaire Screw
42BRACKET (2)
443204326 Frigidaire Bracket Assembly
46SCREW (2)
48137455500 Frigidaire Lower Pan Assembly
50SAFETY COVER
51131168200 Frigidaire Dryer Screw
535304488479 Frigidaire Washer Hose Clamp
