MRT18CHCZ0 02 – DOOR PARTS

MRT18CHCZ0 02 – DOOR PARTS

Written by

in

MRT18CHCZ0 02 – DOOR PARTS

Products

PositionProduct
*70247INSULATION-BULK (NON-ILLUSTRATED)
1WCI 5303207342
25303207345 Frigidaire Refrigerator Door Gasket
3WCI 5303207346
4RACK, DOOR
5SUPPORT – DOOR RACK, RH
6SUPPORT – DOOR RACK, LH
7WCI 5303290741
8RACK, DOOR
9WCI 5303207343
10PLUG-BUTTON, WHITE, HINGE BRG HOLE
11PANEL-FRZR DOOR, WHITE, W/ INSULATION
12WCI 5303276130
13WCI 5308000255
14240494001 Frigidaire Refrigerator Plug Button
15PANEL-REFR DOOR, WHITE, W/ INSULATION
18WCI 5303273079
18AWCI 5303273081
21AWCI 5308011745
22BEARING-HINGE
585304455651 Frigidaire Refrigerator Screw
