MS3080XYR0 03 – OVEN DOOR AND LATCH

Written by

Products

Position	Product
1	Latch, Board
2	Screw
3	4392027 Whirlpool Microwave Primary Switch
4	Screw
6	Rod, Release
8	Hinge Plate, Lower
9	Screw
10	WP3400094 Whirlpool Screw
11	Hinge Washer
15	Door, Complete (White)
15	Door, Complete (Woodgrain Application)
17	Hinge Plate, Upper
18	Screw (2)
19	Screw
20	Washer, Spring Lock (2)
