MSD2550VES02 11 – UNIT PARTS
Written by
in
MSD2550VES02 11 – UNIT PARTS
Products
Position
Product
NI
Valve, Access (5/8“)
NI
Valve, Access (3/4“)
NI
Valve, Access (1/2“)
NI
VALVE, ACCESS (3/8“)
NI
Valve, Access (5/16“)
NI
VALVE, ACCESS (1/4“)
NI
MAY 876764
NI
LINER (NOT A SERVICEABLE PART)
1
CONNECTOR, WATER
2
Fan, Blade
3
Condenser Assembly (Also Order 7)
4
Screw (3)
5
Clip, Wire
6
MAY 8533993
7
Sleeve, Pressure Switch Hose
8
MAY 2215468
9
MAY 2311725
10
MAY W10174384
11
Start-Device, Combination (Start Relay and Overload)
11
Start-Device, Combination (Start Relay and Overload) (Production)
12
MAY W10210786
13
Capacitator (Production)
14
MAY 489478
15
Evaporator
17
MOTOR, CONDENSOR
18
MAY 1105523
19
Heat Shield
20
Drier
20
Drier
21
Grommet (Production)
21
MAY 2183042
22
Unit Mounting Frame
23
Unit, Harness
24
MAY 2181929
25
MAY 2188175
26
Clip
27
MAY 489473
28
Compressor (Includes Items 9, 12, 20 & 28) (Also Order 876765 Tube Kit)
29
MAY 489340
30
MAY W10332806
31
MAY 2155547
32
MAY 2304891
33
MAY 489396
34
Unit Mounting Rail
35
MAY 8281232
36
MAY 2260517
37
MAY 489427
38
Process Tube
←
