| 1 | Grate-Grill |
| 1 | WP4332752 Whirlpool Clip |
| 2 | Medallion (2) |
| 2 | Clip - Push on |
| 3 | WPY04100165 Whirlpool Surface Element |
| 3 | Block, Terminal |
| 4 | WPW10196406 Whirlpool 6" Chrome Drip Bowl |
| 4 | Element, Grill (208 Volt (Opt.)) |
| 4 | Element, Grill (240 Volt) |
| 5 | Reflector Grid |
| 5 | Cooktop (Almond) |
| 5 | Cooktop (Chrome) |
| 6 | Pin, Terminal (4) |
| 7 | Block, Terminal |
| 8 | Nut, Speed |
| 9 | Pan, Module |
| 10 | Screw No.8x5/8 |
| 11 | Screw |
| 12 | Insulator |
| 13 | Bracket - Term. |
| 14 | DRIP BOWL 8" W/HOLE CHROME |
| 15 | WP3177565 Whirlpool Surface Element |
| 16 | Terminal Block |
| 17 | Screw, No.7-32 x 5/16 |
| 18 | Complete Module (Almond) |
| 18 | Complete Module (Chrome) |
