| 1 | Main Top, Glass |
| 1 | Clamp |
| 2 | Nut, Mount. (2) |
| 2 | Thermal Switch (Small) |
| 2 | Thermal Switch (Large) |
| 3 | Radiant Element, Small |
| 4 | WPW10242957 Whirlpool Element Surface Left Front / Right Rear 2000W |
| 5 | Thermal Switch |
| 6 | Pan-Module |
| 7 | Pin, Terminal (4) |
| 8 | Block, Terminal |
| 9 | Insulator |
| 9 | Nut, Speed |
| 10 | Screw |
| 11 | Element Strap |
| 11 | Pan, Module |
| 12 | Screw, No.8-32 x 1/4 |
| 12 | Clamp, Elmnt. |
| 13 | Cooktop (Chrome) |
| 13 | Cooktop (Almond) |
| 13 | Screw, No.8-32 x 3/8 |
| 14 | WP3147132 Whirlpool Surface Element |
| 14 | Spacer-Heater |
| 15 | WP3147131 Whirlpool Surface Element |
| 15 | Screw |
| 16 | Complete Module (Chrome) |
| 16 | Spring, Heater |
| 16 | Complete Module (Almond) |
| 17 | Bracket, Heater |
| 18 | Screw No.8x5/8 |
| 19 | Speed Nut |
| 20 | Bracket - Term. |
| 21 | Module, Complete |
