PRMC2285AF02 04 – CABINET

PRMC2285AF02 04 – CABINET

Written by

in

PRMC2285AF02 04 – CABINET

Products

PositionProduct
NI5304519116 Frigidaire Refrigerator Harness
NIWCI 519092015
NISCREW, SELF TAPPING, 4.2 X 13
NI811950601 Frigidaire Refrigerator Seal
1811949401 Frigidaire Refrigerator Screw
35304519085 Frigidaire Refrigerator Hinge
8240396801 Frigidaire Refrigerator Tube Clamp
9811949503 Frigidaire Screw
105304519086 Frigidaire Refrigerator Cover
11SHIELD, EYEBROW
125304519067 Frigidaire Refrigerator Spring
135304536150 Frigidaire Cover Assembly
145304519089 Frigidaire Refrigerator Screw
155304524003 Frigidaire Refrigerator PC Board
165304519091 Frigidaire Refrigerator Harness
175304536152 Frigidaire Hinge
185304519093 Frigidaire Refrigerator Switch
195304527992 Frigidaire Freezer Wire Harness with Reed Switch
205304536153 Frigidaire Hinge
215304523011 Frigidaire Refrigerator Light Board
22LENS, LED LIGHT, DOUBLE
235304520058 Frigidaire Refrigerator Guide Assembly
24SCREW
25LENS, LED LIGHT
265304519100 Frigidaire Refrigerator Cover
27Support, drawer slider, RH middle
29Cover, divider, top
305304523899 Frigidaire Refrigerator Support
315303918849 Frigidaire Refrigerator Housing Kit
325304519104 Frigidaire Refrigerator Hinge
335303918850 Frigidaire Refrigerator Thermistor Kit
345304519105 Frigidaire Refrigerator Bracket
35811998302 Frigidaire Refrigerator Shaft
365304519106 Frigidaire Refrigerator Foot
37811666601 Frigidaire Refrigerator Roller
385304519107 Frigidaire Support
395304523900 Frigidaire Refrigerator Support
405304519109 Frigidaire Refrigerator Bracket
415304526847 Frigidaire Screw Assembly
455304519111 Frigidaire Refrigerator Clip
465304519112 Frigidaire Refrigerator Cover
49808199001 Frigidaire Screw
505304523032 Frigidaire Refrigerator Screw
515304532193 Frigidaire Refrigerator PC Board
525304526795 Frigidaire Refrigerator PC Board
545304519115 Frigidaire Refrigerator Power Control Board
555304519117 Frigidaire Cover
