PRT215MCD5 04 – SHELVES, CONTROLS, DIVIDER, MULLION

Products

Position	Product
1	WCI 218252504
5	WCI 218271402
6	WCI 218279800
7A	WCI 5303001380
7	WCI 3019038
8	WCI 5303019039
8B	HARNESS-WIRING, CONTROL/DIVIDER (NOT ILLUSTRATED)
8A	3205266 Frigidaire Refrigerator Edge Protector
9	BOTTOM, FREEZER
10	215667501 Frigidaire Refrigerator Ice Tray Primary
11A	SPACER, FRZR SHELF (NOT ILLUSTRATED)
11	WCI 5303288243
12	DEFLECTRO, AIR, W/SEAL
12A	5303001449 Frigidaire Refrigerator Seal
13A	EXTENSION, AIR DEFLECTOR, WITH INSULATION
13	WCI 5303001448
14	5309918806 Frigidaire Refrigerator Light Switch Door
15	316538904 Frigidaire Oven Lamp Light
16A	218906802 Frigidaire Light Lamp Socket
17A	NUT, ANCHOR (NI)
17	WCI 3206130
18	WCI 5303209251
19	WCI 3206129
21A	WCI 5303001260
21	WCI 5303018894
22	WCI 3018891
23	215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
23A	5304455649 Frigidaire Refrigerator Screw
24	WCI 215919118
25	WCI 5303206538
25A	WCI 5303302753
26	WCI 215791908
26A	WCI 5303299775
27	SUPPORT-CRISPER CVR, ADJUSTABLE
28	END CAP-SHELF,PROTECTOR
29	WCI 215919718
31	WCI 5303299809
32	WCI 3201414
33	GASKET-CRISPER COVER (NON-ILLUSTRATED)
34	WCI 5303207065
35A	WCI 3201411
35	WCI 3201409
36	WCI 215919116
36A	FRAMER, HALF SHELF, CATILEVER
37A	WCI 215919716
37	WCI 215919717
40	GLASS-FULL SHELF
41	WCI 215919805
42A	HANGER-PAN/BASKET, RH
42	HANGER-PAN/BASKET, LH
43	WCI 215723547
43A	WCI 215723544
44	TRIM-GLASS SHELF,13.07“ ,REAR
44A	WCI 215919810
47	WCI 5303209283
59	240442708 Frigidaire Refrigerator Screw-#10-32 X 3/4
81	5304455650 Frigidaire Refrigerator Screw
123	215005101 Frigidaire Refrigerator Screw
