PRT215MCW5 02 – DOOR SECTION

PRT215MCW5 02 – DOOR SECTION

Written by

in

PRT215MCW5 02 – DOOR SECTION

Products

PositionProduct
*96680INSULATION
1WCI 215608913
2WCI 215732413
3WCI 5303206513
4ARACK-DOOR, SHORT, NARROW, (2)
4BWCI 5303206515
4WCI 5303206518
5WCI 3206150
5A3206165 Frigidaire Bar Endcap Right Hand
5BSUPPORT-DOOR RACK, EXTENDS 1.06“, RH
6BSUPPORT-DOOR RACK, EXTENDS 1.06“, LH
6A3206166 Frigidaire Refrigerator Freezer Door Shelf Retainer Bar Endcap Rack Support
6WCI 3206151
7WCI 215634805
8AWCI 5303206511
8RACK-DOOR, FULL-WIDTH, WIDE
9WCI 5303206509
10PLUG-BUTTON, WHITE, HINGE BRG HOLE
11WCI 5303916335
12WCI 3206159
12ATAPE, ADHESIVE, 12“ LG, FOAM, DOUBLE-FACED (NOT ILLUSTRATED)
12BTAPE, ADHESIVE, 60“ LG, FOAM, TRIM/NAMEPLATE, DOUBLE FAC
13DOOR STOP, REFR SECTION
13AWCI 218249001
14240494001 Frigidaire Refrigerator Plug Button
15WCI 5303916340
17WCI 5300177143
17AWCI 5300179271
18AWCI 5300177144
18AWCI 5303276925
18HANDLE-DOOR, 44“ LONG, W/ END CAPS
20AWCI 5300179270
20WCI 5300177142
21B218252201 Frigidaire Refrigerator Screw
21AWCI 5308011745
22BEARING-HINGE
36WCI 3206189
585304455651 Frigidaire Refrigerator Screw
