PRT215MCW5 04 – SHELVES, CONTROLS, DIVIDER, MULLION

PRT215MCW5 04 – SHELVES, CONTROLS, DIVIDER, MULLION

Written by

in

PRT215MCW5 04 – SHELVES, CONTROLS, DIVIDER, MULLION

Products

PositionProduct
1WCI 218252503
5WCI 218271402
6WCI 218279800
7AWCI 5303001380
7WCI 3019038
8A3205266 Frigidaire Refrigerator Edge Protector
8WCI 5303019039
8BHARNESS-WIRING, CONTROL/DIVIDER (NOT ILLUSTRATED)
9BOTTOM, FREEZER
10215667501 Frigidaire Refrigerator Ice Tray Primary
11WCI 5303288243
11ASPACER, FRZR SHELF (NOT ILLUSTRATED)
12A5303001449 Frigidaire Refrigerator Seal
12DEFLECTRO, AIR, W/SEAL
13WCI 5303001448
13AEXTENSION, AIR DEFLECTOR, WITH INSULATION
145309918806 Frigidaire Refrigerator Light Switch Door
15316538904 Frigidaire Oven Lamp Light
16A218906802 Frigidaire Light Lamp Socket
17ANUT, ANCHOR (NI)
17WCI 3206130
18WCI 5303209251
19WCI 3206129
21WCI 5303018894
21AWCI 5303001260
22WCI 3018891
23A5304455649 Frigidaire Refrigerator Screw
23215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
24WCI 215919118
25AWCI 5303302753
25WCI 5303206538
26AWCI 5303299775
26WCI 215791908
27SUPPORT-CRISPER CVR, ADJUSTABLE
28END CAP-SHELF,PROTECTOR
29WCI 215919718
31WCI 5303299809
32WCI 3201414
33GASKET-CRISPER COVER (NON-ILLUSTRATED)
34WCI 5303207065
35WCI 3201409
35AWCI 3201411
36WCI 215919116
36AFRAMER, HALF SHELF, CATILEVER
37AWCI 215919716
37WCI 215919717
40GLASS-FULL SHELF
41WCI 215919805
42AHANGER-PAN/BASKET, RH
42HANGER-PAN/BASKET, LH
43WCI 215723547
43AWCI 215723544
44TRIM-GLASS SHELF,13.07“ ,REAR
44AWCI 215919810
47WCI 5303209283
59240442708 Frigidaire Refrigerator Screw-#10-32 X 3/4
815304455650 Frigidaire Refrigerator Screw
123215005101 Frigidaire Refrigerator Screw
