PRT217MCH1 02 – DOOR PARTSadmin2025-04-26T10:26:17+00:00PRT217MCH1 02 – DOOR PARTS
Products
| Position | Product |
|---|
| *42921 | INSULATION-BULK (NON-ILLUSTRATED) |
| 1 | PANEL-FRZR DOOR, WHEAT |
| 2 | BUTTON-WHEAT |
| 3 | BEARING-HINGE |
| 4 | WCI 3206159 |
| 5A | WCI 5308000255 |
| 5 | DOOR STOP, REFR SECTION |
| 8 | BUTTON-WHEAT |
| 9 | WCI 5308011745 |
| 10 | WCI 5318680314 |
| 11 | WCI 5303206509 |
| 12 | RACK-DOOR, FULL-WIDTH, WIDE |
| 13A | SUPPORT-DOOR RACK, EXTENDS 1.06``, LH |
| 13 | SUPPORT-DOOR RACK, EXTENDS 1.06``, RH |
| 15 | RACK-DOOR, SHORT, NARROW, (2) |
| 17 | HANDLE-FREEZER |
| 18 | 5304455651 Frigidaire Refrigerator Screw |
| 19 | WCI 5303018792 |
| 20 | WCI 5303206518 |
| 21 | WCI 5303206513 |
| 22 | PANEL-REFR DOOR, WHEAT |
| 23B | WCI 5300179271 |
| 23 | WCI 5300177143 |
| 24 | WCI 5303206511 |
| 25 | WCI 3206189 |
| 26A | WCI 3206151 |
| 26 | WCI 3206150 |
| 27 | WCI 5303206515 |
| 28 | 3206165 Frigidaire Bar Endcap Right Hand |
| 28A | 3206166 Frigidaire Refrigerator Freezer Door Shelf Retainer Bar Endcap Rack Support |
| 29 | DOOR-DAIRY (INCLUDES TRIM) |
| 30B | WCI 5300179270 |
| 30 | WCI 5300177142 |
| 30A | WCI 5300177144 |
| 31 | HANDLE-REF |
