R21CL6 02 – BACKGUARD AND COOKTOP PARTS

R21CL6 02 – BACKGUARD AND COOKTOP PARTS

Written by

in

R21CL6 02 – BACKGUARD AND COOKTOP PARTS

Products

PositionProduct
1TOP-ALMOND
2PANEL SWITCH-ALMOND
3318372210 Frigidaire Oven Range 6" 1250W Surface Element
3A316442300 Frigidaire Oven 2100W Coil Element 8
4A316048413 Frigidaire Oven Range Chrome 8" Drip Bow
4316048414 Frigidaire Oven Range Chrome 6" Drip Bowl
55303935058 Frigidaire Oven Burner Receptacle Kit
75303935086 Frigidaire Oven Top Burner Switch Kit
8KNOB-SURFACE (4)
9WCI 5303015184
10THERMOSTAT KNOB
11INDICATOR LIGHT
12LEN-PILOT LIGHT
13WCI 5308067828
14PANEL-BKGRD ALMOND
15WCI 3016214
16BRACE (2)
