R24CL5 03 – BACKGUARD AND COOKTOP PARTS

R24CL5 03 – BACKGUARD AND COOKTOP PARTS

Written by

in

R24CL5 03 – BACKGUARD AND COOKTOP PARTS

Products

PositionProduct
1WCI 3014544
2WCI 3016977
3PANEL-BACKGUARD-ALMOND
4318372210 Frigidaire Oven Range 6" 1250W Surface Element
4A316442300 Frigidaire Oven 2100W Coil Element 8
5WCI 303205286
5A316048414 Frigidaire Oven Range Chrome 6" Drip Bowl
65303935058 Frigidaire Oven Burner Receptacle Kit
7WCI 3016958
95303935086 Frigidaire Oven Top Burner Switch Kit
10WCI 5303015184
11INDICATOR LIGHT
12KNOB-SURFACE (4)
14THERMOSTAT KNOB
15BRACE (2)
16MEDALLION, STAINLESS STEEL, SURF ELEM
