RA186GCW5 02 – DOOR PARTS

Products

Position	Product
1	WCI G172367-01
2	BEARING, HINGE (3)
3	240494001 Frigidaire Refrigerator Plug Button
4	GASKET DOOR
5	5308000716 Frigidaire Refrigerator Dish
6	RACK-DOOR (2)
7	SUPPORT-RS (5)
8	SUPPORT-LS (5)
9	WCI G162855-47
10	WCI G164109-15
11	END CAP RS (2)
12	END CAP LS (2)
13	WCI G167115
14	WCI G101890
15	218843801 Frigidaire Refrigerator Screw
16	WCI G177398-01
17	WCI G173948-15
18	BUMPER-LIGHT SW.
19	STOP, DOOR. PC & FC (2)
20	WCI G169332-01
21	WCI G177141-02
22A	TRIM, BTM
22	CAP
23A	TRIM, TOP
23	CAP
23B	CLIP
24	WCI G185566
25	WCI G176985
25	WCI G169487-01
