RA30NL1 04 – COOKTOP AND BROILER PARTS

Products

Position	Product
1	WCI 3051380
2A	318372210 Frigidaire Oven Range 6" 1250W Surface Element
2	316442300 Frigidaire Oven 2100W Coil Element 8
3	316048413 Frigidaire Oven Range Chrome 8" Drip Bow
3A	316048414 Frigidaire Oven Range Chrome 6" Drip Bowl
4	WCI 5308067828
5	5303935058 Frigidaire Oven Burner Receptacle Kit
6A	BRACKET-HINGE,MAIN TOP RH
6	BRACKET-HINGE,MAIN TOP LH
7	ROD - MAINTOP SUPT.
8	WCI 5303212929
9	WCI 3204623
10	WCI 5303133767
10A	5303935086 Frigidaire Oven Top Burner Switch Kit
11	WCI 5303210266
12A	WCI 5303212928
12	WCI 5303212927
13	WCI 5303210270
14	JEWEL-IND
15	316075103 Frigidaire Oven Bake Element
16	5303051140 Frigidaire Broil Element
17	316203400 Frigidaire Oven Support
