RAL6245AG0 02 – TOP AND CABINET, LIT/OPTIONAL

Products

PositionProduct
WPL LIT3358678
Golden Harvest
Golden Harvest (Uncut)
Shipping Kit
WPL 89121
WPL LIT881005
LUBRICANT (USE ONLY IN BRAKE SHOE ASSEMBLY ON ROLLER & PIN)
WP285195 Whirlpool Sealer Assembly
Manual, (Washer) Do-It-Yourself
WPL LIT3358743
WPL LIT3358964
Guide, Use and Care
72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
63580 Whirlpool Washer Fabric Softener Dispenser
350572 Whirlpool Oil Transmission 15 Oz
WP72107 Whirlpool Touchup
Leveler (Thinner)
72017 Whirlpool Appliance Touch-Up Paint White
350956 Whirlpool Spray Assembly
Almond (Uncut)
350938 Whirlpool Spray Gun
285320 Whirlpool Washer Siphon Break Kit
Drain Protector (Not Included)
350930 Whirlpool White Spray Paint
799344 Whirlpool Refrigerator Paint
1WP357213 Whirlpool Hinge Stopper
2Top (Golden Harvest)
2Top (For Almond Model)
2Top (For White & Desinger White Models)
3WP62750 Whirlpool Spacer
563424 Whirlpool Cabinet Assembly
5Cabinet (Golden Harvest)
5Cabinet (Almond)
6WP62780 Whirlpool Cabinet Clip
8WP3356311 Whirlpool Screw
11285671 Whirlpool Lid Switch Assembly
13SCREW
14WP21097 Whirlpool Pad
15WP54584 Whirlpool Hinge
16WP54583 Whirlpool Hinge
17Bumper, Lid Hinge
18WP21258 Whirlpool Washer Lid Hinge Bearing
19Lid (White)
19Lid (Almond)
19Lid (Golden Harvest)
20WP358684 Whirlpool Strike Assembly
22WP9724509 Whirlpool Bumper
28SCREW
30Rivet, Serial Nameplate
31WP90016 Whirlpool Clip
33WP3362952 Whirlpool Bezel
