RB1200XKW0 04 – SECTION

Products

Position	Product
1	WP965173 Whirlpool Dishwasher Screw
1	Screw (3)
1	Liner, Door
1	Washer, Fiber
2	Door Stop Replacement Kit
3	SCREW
3	Bar, Torsion (L.H.)
3	Bar, Torsion (R.H.)
3	Bar, Torsion (Pushnut (2))
4	Seal, Window
5	Glass, Inner
6	Baffle, Insulation
8	Screw, 10A x 1/2 (2) (Black)
8	spacer, insulation baffle (4)
9	Channel, Rubber (4)
10	Panel, Oven Door (Coffee)
10	Panel, Oven Door (New Avocado)
10	Panel, Oven Door (White)
10	Panel, Oven Door (Almond)
10	Panel, Oven Door (Harvest Gold)
10	Panel, Oven Door (Platinum)
10	panel, top (screw, 10a x 3/8 (3))
10	Panel, Oven Door (Toast)
11	Nut, Snap-In (2)
11	Handle, Oven Door
11	WP308499 Whirlpool Nut
12	Frame, Window
13	Retainer, Glass
14	Clip, Frame
15	Screw
15	Glass, Outer
15	Hinge-Lt. or Rt.
