RB160PXL0 03 – OVEN, LIT/OPTIONAL

Products

Position	Product
1	Oven (27“ Pyro)
2	Socket, Light
3	RANGE ONLY 40W 120V APPL BULB
3	Washer (2)
4	Gasket, Light
5	Cover, Light
6	retainer, oven light
7	Bracket, Thermo Bulb
9	Unit, Broil
10	Hanger, Broil Unit
10	Unit Bake (Screw, 10-24 x 1/2 (2))
11	WP866375 Whirlpool Range Bake Element
12	Heater, Mullion
13	Clip, Heater R.H.
13	Clip, Heater L.H.
14	vent tube (alternate)
14	Screw, 10-24 x 3/8 (2)
14	vent tube (alternate)
15	Retainer, Insulation Side (2)
16	Retainer, Insulation Top
17	Retainer, Insulation Bottom
18	Casing, Back
19	Casing, Bottom
20	Support, Bottom Casing (2)
21	Spacer Trim (4)
22	Trim, Oven Front (2)
23	Casing, Side (2)
24	Plate, Conduit
25	Hex Nut, 10-32 (6)
25	Screw,10-24 x 1/2
25	WPL 834649
25	WP8203546 Whirlpool Terminal Block
33	Screw, 10-24 x 1/2 (3)
33	Cover, Access
34	Rack, Oven Regular
35	Rack, Oven (Offset)
36	4396923 Whirlpool Broil Pan Set Gray Porcelain
37	Pan, Broiler
38	1
38	FOIL, ALUMINUM OVEN (18“ X 25 )
38	WPW10208653 Whirlpool Insulation
38	Touch-Up Oven (1 Oz.)
38	WPL 877603
38	WPL 866338
38	Grease
38	WPL 308500
38	Wire, 25` Roll (Black 14 Ga.)
38	Wire, 25` Roll (Red 14 Ga.)
38	Wire, 25“ Roll (White 14 GA.)
38	Wire (14 Ga. 200 c Brown)
38	Plug, Button
38	18 Ga. 80~c Rating (Red)
38	Wire (12 Ga. 150 c Black)
38	Wire (14 Ga. 150 c Yellow)
38	Wire (14 Ga. 150 c Orange)
38	WPL 980573
38	Wire (14 Ga. 150 c Brown)
38	Wire (14 Ga. 150 c Blue)
38	242831 Whirlpool Oven Wire
38	Wire (14 Ga. 150 c Green)
