RB636*01

RB636*01

Written by

in

RB636*01

Products

Position	Product
1	GEN WB48X5053
1	GEN WB38X5032
1	WB21X36771 GE Surface Element Switch
2	GEN WB63X5132
2	WZ4X345D GE Screw Package 12 C92
2	SWITCH, SELECTOR
2	SUPPORT BROIL
2	GEN WB44X5074
3	WB1X119D GE Oven Range Washer
3	GEN WB19X5206
3	LINER SCREW
3	GEN WB53X5067
3	GEN WB02X5208
3	GEN WB02X5816
3	GEN WB63X5118
3	GEN WB02X5206
3	GEN WB01X5221
4	GEN WB02X5545
4	GEN WB02X5889
4	GEN WB49X5052
4	THERMOSTAT – UPPER OVEN
4	GEN WB01X5432
4	GEN WB02X5639
5	GEN WB49X5117
5	GEN WB63X5133
5	GEN WB61X5726
5	GEN WB61X5724
5	WB17X5095 GE Black Oven Terminal
5	GEN WB61X5725
5	GEN WB61X5727
6	GEN WB07X5368
6	GEN WB07X5506
6	GEN WB38X5037
6	GEN WB02X5638
7	GEN WB03X5479
7	GEN WB49X5005
7	GEN WB63X5120
8	CLIP FOR THERMOSTAT TUBE
8	GEN WB03X5503
8	GEN WB63X5096
9	GEN WB03X0218
9	OVEN LINER MOUNTING SPRING
9	GEN WB63X5183
10	GEN WB24X5016
10	GEN WB02X1083
10	SLEEVING AT TERMINALS
10	GEN WB07X5035
10	GEN WB02X5556
10	GEN WB01X5220
11	SCREW – INCL. WASHERS NO. 10-24X1/2"
11	GEN WB36X5056
11	LAMP – RECEPTACLE
11	GEN WB55X5180
11	SPEEDNUT ON HANDLE SUPPORT
12	GEN WB56X5575
12	GEN WB56X5573
12	GEN WB02X5804
12	GEN WB56X5574
12	WB36X192 GE Oven Light Cover
12	GEN WB56X5576
12	KNOB THERMSOTAT U.O.
13	GEN WB08X5040
13	GEN WB02X6365
13	GEN WB02X2885
13	HANDLE SCREW
13	SPACER
14	CAM LINK
14	CLIP MTG LAMP
14	WB48X10056 GE Broil Pan Set, Large Porcelain
14	NEON LAMP 118V
15	GEN WB02X5410
15	GEN WB31X5355
15	WB30X218 GE Range Cooktop Burner Unit 6 Inch
16	TRIM PLATE LOWER OVEN
16	GEN WB32X0052
16	GASKET – TOP & SIDES
16	GEN WB02X5084
17	WB44X5043 GE Oven Range Bake Element
17	GEN WB02X5218
17	WB31X5013 GE Oven 6" Chrome Trim Ring
18	GEN WB56X5580
18	GEN WB56X5579
18	GEN WB56X5578
18	GEN WB56X5577
18	GEN WB02X5521
18	WB30X219 GE Range Cooktop Burner Unit 8 Inch
18	FOOT FOR BAKE UNIT
18	SCREW RECEPT TERMINAL
19	GEN WB32X0051
19	GEN WB15X0094
19	GEN WB01X5272
19	GEN WB01X0120
20	GEN WB58X5003
20	GEN WB02X5116
20	TRIM RING 8"
22	SLIDE-NYLON(AT FRONT OF GUIDE)
22	GUIDE DRAWER
22	GEN WB02X6171
23	GEN WB56X5181
23	CLIP INSULATOR
23	GEN WB56X5178
23	GEN WB56X5222
23	GEN WB02X5522
23	GEN WB56X5267
24	WINDOW GASKET
25	GEN WB36X5113
25	WB17X5051
26	GEN WB02X5506
27	OUTER WINDOW – PATTERNED
27	RR122 Supco Receptacle WB17X5051
28	WINDOW BRACKET
29	GEN WB10X5043
29	RETAINING RING FOR HINGE PIN
29	HINGE PIN FOR SERVICE 3/16" DIA.
30	GEN WB10X5021
30	GEN WB10X5026
31	GEN WB10X5024
31	GEN WB10X5023
32	GEN WB09X5017
32	WB32X10012 GE Oven Range Cooktop 6" Chrome Drip Pan
33	GEN WB10X5020
33	WB32X10013 GE Oven 8" Chrome Drip Pan
33	GEN WB10X5027
34	GEN WB62X5082
34	GEN WB01X5147
34	GEN WB02X5544
34	GEN WB62X5083
34	GEN WB62X5090
34	GEN WB62X5110
34	DOOR SUPPORT – LH & RH
35	GEN WB10X5041
35	GEN WB10X5042
35	SPEC. SCREW – TRIMMED HD. 1/2-28X3/8"
35	GEN WB14X5021
36	GEN WB09X5018
36	GEN WB01X5180
37	GEN WB02X5748
37	WB25X65 GE Oven Light Indicator
38	FUSE RECEPTACLE – INCL. FUSE (04)
