RB636*A1

RB636*A1

Written by

in

RB636*A1

Products

Position	Product
1	GEN WB61X5993
1	GEN WB61X5996
1	GEN WB61X5995
1	GEN WB61X5994
1	GEN WB61X5992
2	GEN WB63X5193
3	WB21X36771 GE Surface Element Switch
4	GEN WB03X5479
5	SWITCH, SELECTOR
6	GEN WB03X5503
7	GEN WB01X5218
7	GEN WB02X5760
7	THERMOSTAT – UPPER OVEN
8	KNOB THERMSOTAT U.O.
9	NEON LAMP 118V
10	CLIP MTG LAMP
11	WB25X65 GE Oven Light Indicator
12	GEN WB19X0148
13	GEN WB36X5321
14	GEN WB07X5607
15	GEN WB02X3325
16	GEN WB03X0459
17	GEN WB07X6692
17	GEN WZ05X0250
17	GEN WB07X6691
20	SPEEDNUT MTG TRIM
20	GEN WB07X5638
21	GEN WB04X0350
21	GEN WZ04X0319
21	GEN WB62X5230
21	GEN WB62X5226
21	GEN WB62X5227
21	GEN WB62X5228
21	GEN WB62X5229
21	GEN WB02X5165
22	LINER SCREW
22	GEN WB07X5613
22	GEN WB07X5612
40	WB30X342 GE Oven Cooktop 6" Burner Unit 3w No Trim Ring
41	WB31X5013 GE Oven 6" Chrome Trim Ring
42	WB32X10012 GE Oven Range Cooktop 6" Chrome Drip Pan
43	GEN WB32X0052
43	GEN WB32X0051
44	WB1X500D GE Oven Screw Package
44	WB30X348 GE Oven 8" Surface Unit Element with Screw
44	GEN WB01X5485
45	WB31X5014 GE 8-Inch Chrome Trim Ring
46	WB32X10013 GE Oven 8" Chrome Drip Pan
47	TERM BLOCK SINGLE COIL
47	WB2X1351 GE Oven Terminal Block
48	CLIP INSULATOR
70	GEN WB63X5096
73	GEN WB63X5132
74	GEN WB38X5032
75	GEN WB63X5191
76	GEN WB56X5728
76	GEN WB56X5729
76	GEN WB56X5731
76	GEN WB56X5730
76	GEN WB56X5732
77	GEN WB02X5522
78	SWITCH, OVEN LIGHT
78	SLEEVING AT TERMINALS
79	GEN WB63X5183
80	GEN WB63X5190
81	GUIDE DRAWER
82	SLIDE-NYLON(AT FRONT OF GUIDE)
83	GEN WB02X6519
84	PLATE GROUND
84	WB17X5095 GE Black Oven Terminal
85	GEN WB02X6521
87	DOOR GUIDE ASM.-LH & RH
88	HINGE PIN FOR SERVICE 3/16" DIA.
89	RETAINING RING FOR HINGE PIN
90	DOOR SUPPORT – LH & RH
90	GEN WB10X5041
90	GEN WB10X5042
90	SPEC. SCREW – TRIMMED HD. 1/2-28X3/8"
92	GEN WB09X5018
110	GEN WB56X5717
110	GEN WB56X5716
110	GEN WB56X5715
110	GEN WB56X5713
110	GEN WB02X6530
110	GEN WB56X5714
111	GEN WB02X6036
112	SPEEDNUT ON HANDLE SUPPORT
113	GEN WB15X5125
114	GEN WB01X5530
115	GEN WB01X5272
116	GEN WB02X5218
117	GEN WB02X5410
118	CAM LINK
119	TRIM PLATE LOWER OVEN
120	GEN WB01X5484
120	WINDOW BRACKET
121	GEN WB36X5318
122	GEN WB02
