RC131LCF0 03 – CABINET PARTSadmin2025-04-26T08:42:35+00:00RC131LCF0 03 – CABINET PARTS
Products
| Position | Product |
|---|
| *96346 | WCI G177673 |
| *96346 | BASE-CABINET |
| *96345 | BUTTON, PLUG, LINER (2) |
| 1 | TUBE, INSULATION (2) |
| 2B | WCI G103903 |
| 2A | 241710601 Frigidaire Refrigerator Screw |
| 2 | BRACKET, TOP HINGE |
| 3 | WCI G183861 |
| 4 | SHIM, HINGE |
| 4A | TAPPING, PLATE (2) |
| 5B | WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET) |
| 5 | BRACKET, HINGE, LOWER |
| 5A | 5303001321 Frigidaire Refrigerator Lower Hinge Pin |
| 6 | STOPPER-RUBBER |
| 7 | DRIP TRAY |
| 7A | GASKET-TRAY (NON-ILLUSTRATED) |
| 8 | SUPPORT-TRAY RH |
| 9 | WCI G174734 |
| 10 | WCI G174733 |
| 11 | BRACKET-CONTROL |
| 12 | SOCKET LIGHT |
| 13 | 316538904 Frigidaire Oven Lamp Light |
| 14 | WCI G162205-08 |
| 14A | WCI G107080 |
| 15 | WCI G163211-30 |
| 15A | SCREW-GROUND (2) (NON-ILLUSTRATED) |
| 16 | WCI G174781-17 |
| 17 | 5309918806 Frigidaire Refrigerator Light Switch Door |
| 18 | WCI G172172-01 |
| 19 | TRIM, COFFEE |
| 20 | 215667501 Frigidaire Refrigerator Ice Tray Primary |
| 21 | COVER-CRISPER |
| 22 | PAN, STORAGE |
| 23A | NUT, ANCHOR (2) |
| 23 | LEG-LEVELING (2) |
| 24 | WCI G166912 |
| 25 | WCI G179612 |
| 25A | CLIP-CANOE (2) (NON-ILLUSTRATED) |
| 25B | LABEL-BAFFLE (NON-ILLUSTRATED) |
| 26 | COVER HINGE, COFFEE |
| 27 | WCI G174747-10 |
