RD17F3FT3B 03 – CABINET PARTS

Products

PositionProduct
*93566HARNESS, WIRING
*93567BUTTON, LINER
*93565BUTTON, PLUG, LINER (2)
1COVER, TOP HINGE, AVOCADO
2BRACKET, TOP HINGE
2CWASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET)
2BWCI G103903
2A241710601 Frigidaire Refrigerator Screw
3WCI G183861
4ANUT, ANCHOR (2)
4LEG-LEVELING (2)
5BRACKET, HINGE, LOWER
65303001321 Frigidaire Refrigerator Lower Hinge Pin
7SHIM, HINGE
8WCI G156376
9PAN-CRISPER
10PAN-SMALL LS
11COVER-CRISPER
12SUPPORT, CRISPER COVER
13WCI G162178
14DEFLECTOR AIR
15WCI G172410-04
16SHELF
17BUTTON-DECORATIVE
18DAMPER FAN COVER
18ANUT, DAMPER MOUNTING
19KNOB-DAMPER
20WCI G163061-50
21316538904 Frigidaire Oven Lamp Light
22KNOB
23TUBE
24COLD CONTROL
24AWCI G107080
25SOCKET LIGHT
26WCI G176722-03
27WCI G178402-02
28WCI G188379-01
29A5304455649 Frigidaire Refrigerator Screw
29215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
30SPOUT DRAIN TUBE
30APIN PUSH SPOUT (2)
31ARING, SEAL (NON-ILLUSTRATED)
31TUBE, DRAIN
32WCI G101747
335308000010 Frigidaire Refrigerator Evaporator Fan Blade
34RING, FAN ORIFICE
35G187559 Frigidaire Refrigerator Bushing
36WCI G164571
375300158289 Frigidaire Evaporator Fan Motor
38WCI G185302
39WCI G185303
40TUBE, INSULATION (2)
41COVER-COIL
41ANUT, ORIFICE (2)
42BRACKET, HINGE CENTER
42BSCREW, BRACKET MOUNTING (4)
42AWASHER (2)
43WCI G142220
44SPACER, MULLION (2)
45WCI G187921
46MULLION, AVOCADO
47CLAMP, MULLION MOUNTING
48TROUGH-DRAIN
495309918806 Frigidaire Refrigerator Light Switch Door
50DIVIDER, CENTER
51ASCREW (5)
51TOP PC
52BOTTOM, FC
53WCI G163669
54WCI G166512
55WCI G174733
56WCI G174734
57WCI G174747-08
58CABINET BASE
59TRIM CORNER (4), AVOCADO
60PAD, FOAM (2)
