RD19F8WT3A 03 – CABINET PARTS

Products

PositionProduct
1COVER, TOP HINGE, AVOCADO
1COVER HINGE, WHEAT
1COVER HINGE, WHITE
1COVER, TOP HINGE, ALMOND
1COVER HINGE, COFFEE
2BRACKET, TOP HINGE
3BWCI G103903
3A241710601 Frigidaire Refrigerator Screw
3CWASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET)
3WCI G183861
4ANUT, ANCHOR (2)
4LEG-LEVELING (2)
5BRACKET, HINGE, LOWER
65303001321 Frigidaire Refrigerator Lower Hinge Pin
7SHIM, HINGE
8WCI G176639-23
9PAN-SMALL LS
10COVER, CRISPER
11SUPPORT, CRISPER COVER
12DEFLECTOR AIR
13WCI G162178
14WCI G181153-06
15WCI G172410-06
16WCI G184572-04
17WCI G166495-01
18DAMPER FAN COVER
18ANUT, DAMPER MOUNTING
19KNOB-DAMPER
20WCI G163061-81
21316538904 Frigidaire Oven Lamp Light
22KNOB
23TUBE
24COLD CONTROL
25SOCKET LIGHT
26WCI G176722-03
27WCI G178402-02
28215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
28A5304455649 Frigidaire Refrigerator Screw
29APIN PUSH SPOUT (2)
29SPOUT DRAIN TUBE
30ARING, SEAL (NON-ILLUSTRATED)
30TUBE, DRAIN
31WCI G101747
325308000010 Frigidaire Refrigerator Evaporator Fan Blade
33RING, FAN ORIFICE
34G187559 Frigidaire Refrigerator Bushing
35WCI G164571
365300158289 Frigidaire Evaporator Fan Motor
37WCI G185302
38WCI G185303
39TUBE, INSULATION (2)
40WCI G177529
40ANUT, ORIFICE (2)
41BSCREW, BRACKET MOUNTING (4)
41BRACKET, HINGE CENTER
41AWASHER (2)
42SPACER, MULLION (2)
43WCI G142220
44WCI G177254
45WCI G180373-10
45WCI G180373-11
45WCI G180373-09
45MULLION, WHITE
45WCI G180373-08
46STRAP, MULLION MOUNTING
47WCI G177534
485309918806 Frigidaire Refrigerator Light Switch Door
49DIVIDER, CENTER
50BOTTOM, FC
51TOP, PC
51ASCREW (5)
52WCI G163669
53WCI G166912
54WCI G174733
55WCI G174734
56WCI G174747-11
56WCI G174747-09
56WCI G174747-10
56WCI G174747-08
56WCI G174747–01
57WCI G490004-02
58TRIM CORNER (4), AVOCADO
58WCI G179684-09
58TRIM-CORNER, ALMOND (4)
58WCI G179684-10
58WCI G179684-01
59AHARNESS, WIRING
595304509705 Frigidaire Refrigerator Grommet
595304500407 Frigidaire Refrigerator Shelf Mounting Grommet
