RD19F8WU3A 05 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

PositionProduct
*17882HOT TUBE REPAIR KIT
1WCI G162739
2BRACKET-CONDENSER MOUNTING (4)
35308000039 Frigidaire Refrigerator Screw
4HARNESS, WIRING
5HARNESS-COMPRESSOR
6WCI G183584
75304455651 Frigidaire Refrigerator Screw
8CORD, SERVICE
95303001199 Frigidaire Refrigerator Wiring Harness Clamp
10CLAMP-CABLE
11DEFROST PAN & NUT
12NUT, LOCK
135303305677 Frigidaire Replacement Filter Dryer Filters
14CLIP, COMPRESSOR MOUNTING (4)
15WASHER, COMPRESSOR MOUNTING (4)
16218513300 Frigidaire Refrigerator Compressor Mount Grommet
17PLATE
18WCI 3916004
19WCI G182225-18
20WCI G188877
225303006412 Frigidaire Refrigerator Cover Mounting Strap
23CAPACITOR
24STRAP-CAPACITOR
25PAN RETAINER KIT-SERVICE
26HEAT-EXCH
27240396801 Frigidaire Refrigerator Tube Clamp
285317842502 Frigidaire Defrost Heater
29EVAPORATOR
305308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
31INSULATOR
32BLOCK, EVAPORATOR, RH
33PLUG, EVAPORATOR INSULATION BLOCK, R H
34BLOCK, LEFT SIDE
355303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
