RD19F9EU3C 03 – CABINET PARTS

RD19F9EU3C 03 – CABINET PARTS

Written by

in

RD19F9EU3C 03 – CABINET PARTS

Products

Position	Product
*02446	BUTTON, PLUG, LINER (2)
*02445	BUTTON, LINER
*02447	HARNESS, WIRING
1	COVER HINGE, COFFEE
2	BRACKET, TOP HINGE
3B	WCI G103903
3C	WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET)
3	WCI G183861
3A	241710601 Frigidaire Refrigerator Screw
4	ROLLER FRONT, ADJUSTABLE (2)
5B	BOLT ROLLER (2)
5A	5308000039 Frigidaire Refrigerator Screw
5	ROLLER, REAR (2)
6	SPRING-ROLLER (2)
7	BOLT-ROLLER (2)
8	WASHER
9	SUPPORT, ROLLER (2)
10	BRACKET, HINGE, LOWER
11	5303001321 Frigidaire Refrigerator Lower Hinge Pin
12	SHIM, HINGE
13	WCI G153376-13
14	WCI G176639-29
15	WCI G177343-18
16	WCI G490015-49
17	TRIM
18	WCI G163022-03
19	WCI G177343-19
20	WCI G187181-02
21	COVER, CRISPER
21A	GASKET, COVER
22	SUPPORT, CRISPER COVER
23	WCI G162178
24	DEFLECTOR AIR
25	WCI G171608-14
26	WCI G171654-51
27	TRIM (3)
28	TRIM, SHELF, REAR (3)
29	WCI G171654-54
30	TRIM
31	WCI G172436-19
32	WCI G186661-02
33	WCI G186665-02
36	TRIM, SHELF, REAR, MEAT KEEPER
37	HANGAR, LEFT SIDE
37	HANGAR, RIGHT SIDE
38	WCI G187218-10
39	TRIM
40	SHELF
41	WCI G166495-01
42	BUTTON-DECORATIVE
43	DAMPER FAN COVER
43A	NUT, DAMPER MOUNTING
44	WCI G163061-76
44A	5304455650 Frigidaire Refrigerator Screw
45	KNOB
46	LABEL, COVER
47	316538904 Frigidaire Oven Lamp Light
48	KNOB
49	TUBE
50A	WCI G107080
50	COLD CONTROL
51	SOCKET LIGHT
52	WCI G176722-03
53	WCI G178402-02
54	WCI G188379-02
55A	5304455649 Frigidaire Refrigerator Screw
55	215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
56	SPOUT DRAIN TUBE
56A	PIN PUSH SPOUT (2)
57	TUBE, DRAIN
57A	RING, SEAL (NON-ILLUSTRATED)
58	WCI G101747
59	5308000010 Frigidaire Refrigerator Evaporator Fan Blade
60	RING, FAN ORIFICE
61	G187559 Frigidaire Refrigerator Bushing
62	WCI G164571
63	5300158289 Frigidaire Evaporator Fan Motor
64	WCI G185302
65	WCI G185303
66	TUBE, INSULATION (2)
67	WCI G177529
68	NUT, ORIFICE (2)
69A	WCI G162220
69D	SPACER, MULLION (2)
69B	WASHER (2)
69C	BRACKET, HINGE CENTER
70	WCI G177254
71	WCI G180373-10
72	STRAP, MULLION MOUNTING
73	WCI G177534
74D	SCREW (3) (NON-ILLUSTRATED)
74	CHANNEL, SHELF (2)
74C	SPACER, FREEZER (2)
74B	CHANNEL, CENTER SHELF, MOUNTING
74A	5304455852 Frigidaire Refrigerator Screw
75	5309918806 Frigidaire Refrigerator Light Switch Door
76	DIVIDER, CENTER
77	BOTTOM, FC
78A	SCREW (5)
78	TOP, PC
79	WCI G163669
80	WCI G166912
81	WCI G174733
82	WCI G174734
83	WCI G174747-10
84	5304509705 Frigidaire Refrigerator Grommet
84	5304500407 Frigidaire Refrigerator Shelf Mounting Grommet
85	WCI G490004-02
86	WCI G179684-10
