RE37BNL1 02 – BACKGUARD

Products

Position	Product
1	COVER, WIRE.
2	5303935086 Frigidaire Oven Top Burner Switch Kit
3	THERMOSTAT
4	LIGHT-PILOT OVEN & CLEAN
4	INDICATOR LIGHT, OVEN
5	LENS (3)
6	WCI 5308015771
7	PANEL-CONTROL, METAL
8	LAMP-FLUORESCENT, BACKGROUND
9	WCI 5303211404
10	RECEPTACLE-LAMP, RH / LH
11	WCI 5303211871
12	BRACKET-MTG CLOCK
13	WCI 3205397
14	WCI 08012745
14A	WCI 08012746
15	SUPPORT RH
15A	SUPPORT LH
16	BRACKET, HINGE (2)
17	NUT – HEX FLAT
18	KNOBS-GRAY & BURGUNDY (6)
19	KNOB – CLOCK (3) – GREY
20	WCI 08012708
21	NUT-KNURLED
22	WCI 5303211403
23	STARTER-LAMP
