| 1 | WCI K1301788 |
| 3 | SWITCH SELEC. |
| 4 | WCI K5132401 |
| 5 | BRACKET |
| 7 | COVER, WIRE |
| 8B | SWITCH-SURFACE UNIT (4) |
| 8 | 5303935086 Frigidaire Oven Top Burner Switch Kit |
| 9 | SUPPORT-BACKGRD RH |
| 10 | WCI G5128105 |
| 11 | NUT (3) |
| 12 | WCI G5128001 |
| 13 | WCI K5139002 |
| 14 | SCREW - THERMO BRACKET 6-32 X 3/16 (2) |
| 17 | KNOB OVEN SELECTOR |
| 18 | WCI K1167946 |
| 19 | GLASS |
| 20 | WCI K5260301 |
| 21A | SCREW |
| 21 | BRACKET MOUNTING |
| 23 | WCI K5137604 |
| 25 | WCI K5128002 |
| 26 | WCI K5128106 |
| 27 | WCI K5127702 |
| 28 | 08002868 Frigidaire 0 Screw Assembly |
| 29 | WCI K5265801 |
| 30 | SIGNAL LIGHT - OVEN |
| 31 | SIGNAL LIGHT-SURF UNIT |
| 32 | SCREW |
