REG34NL2 05 – DOOR PARTS

Products

Position	Product
*39093	INSULATION-AIRWASH (2)
1	PANEL-DOOR (ALMD)
2	GASKET-WINDOW
3	WCI 5301167830
4	BAFFLE
5	WCI 3206078
6	INSULATION-BAFFLE
7B	COLLAR-GLASS
7	WCI 5303212548
8	HANDLE
9	WCI 5301318805
10	BUTTON PLUG
11	SCREW 10 X 24 (2)
12	WASHER-PADDED (3) (NON-ILLUSTRATED)
13	DOOR LINER
14	HINGE, ASSY (2)
15	WCI 5308003186
16	WCI K5104201
17	MOULDING OUTER GLASS
18	WCI 5301313341
19	INSULATION- AIRWASH
20	PANEL-AIRWASH
23	SPACER (2)
26	GLASS-OVEN DOOR, HEAT BARRIER, (2)
27	GLASS-OUTER
28	PANEL-INSULATOR PAD
