REG38BNL1 05 – BODY PARTS

Products

PositionProduct
*34052ANTI-TIP KIT, (NON-ILLUSTRATED)
1BSIDE PANEL RH-ALMD
1CSIDE PANEL LH-ALMD
3BUMPER, COOKTOP (4)
4RETAINER, INSULATION (2)
5SCREW-LEVELING (4)
6WCI 5308015746
6ARAIL, DRAWER LH
7GUIDE-DRAWER FRNT (2)
8BUTTON-PLUG
9WCI 5303207514
10WCI 3051511
11316116400 Frigidaire Oven Light Socket
12316538904 Frigidaire Oven Lamp Light
13RETAINER-LENS
145304524341 Frigidaire Lens
15SPACER, DRAWER RAIL (2)
16GRILLE, BROILER
17WCI 3205539
18316067902 Frigidaire Oven Rack
18ARACK-OFFSET
195304409888 Frigidaire Oven Terminal Block with Hardware
20PLATE=GROUND STRAP
21WCI 5303207390
22WCI 3206275
23WCI 08067758
25PLUG BUTTON (NON-ILLUSTRATED)
26316217002 Frigidaire Oven Temperature Probe
27WCI 3201632
28WCI 3051634
29INSULATION
30WCI 3017481
30AWCI 3017482
31WIRE, COVER
32PANEL-BACK
33WCI 08012542
34WCI 3205260
35WCI 08007445
36WCI 08007444
37WCI 5303207391
38WCI 3016281
39WCI 3201631
40BRACKET-LIGHT SWITCH
41TUBE-OVEN VENT
42LATCH – MOTOR
46LATCH-DOOR
47HOUSING-DOOR LATCH
48AXLE – HINGE (2)
49WCI 3051649
50WCI 3202393
53WCI 3019063
54BALLAST-LAMP (NON-ILLUSTRATED)
55WCI 3206095
56WCI 3202082
