REGS37BNL2 04 – BODY PARTS

Products

Position	Product
*44950	WCI 19100210083
1A	SIDE PANEL LH-ALMD
1	SIDE PANEL RH-ALMD
3	BUMPER, COOKTOP (4)
4	RETAINER, INSULATION (2)
5	SCREW-LEVELING (4)
6A	RAIL, DRAWER LH
6	WCI 5308015746
7	GUIDE-DRAWER FRNT (2)
8	WCI 3051784
9	WCI 5303207514
10	WCI 3051511
11	316116400 Frigidaire Oven Light Socket
12	316538904 Frigidaire Oven Lamp Light
13	RETAINER-LENS
14	5304524341 Frigidaire Lens
15	SPACER, DRAWER RAIL (2)
16	GRILLE, BROILER
17	WCI 3205539
18	316067902 Frigidaire Oven Rack
18A	RACK-OFFSET
19	5304409888 Frigidaire Oven Terminal Block with Hardware
20	PLATE=GROUND STRAP
21	WCI 3205257
22	WCI 3206275
25	PLUG BUTTON (NON-ILLUSTRATED)
27	WCI 5303207389
28	WCI 3051634
29	INSULATION
30	WCI 3017481
30A	WCI 3017482
31	WIRE, COVER
32	PANEL-BACK
33	WCI K005025704
33A	WASHER-PADDED
34	WCI 3205260
35	WCI 08007445
36	WCI 08007444
37	WCI 3051655
38	BRACKET, VENT TUBE
39	GASKET, OVEN VENT TUBE
40	BRACKET-LIGHT SWITCH
41	TUBE-OVEN VENT
42	LATCH – MOTOR
46	LATCH-DOOR
47	HOUSING-DOOR LATCH
48	AXLE – HINGE (2)
49	WCI 3051649
50	WCI 3016281
50A	316217002 Frigidaire Oven Temperature Probe
51	WCI 3202082
52	WCI 3202393
53	WCI 3201631
54	WCI 3019063
55	WCI 5303207390
55A	ANTI-TIP KIT, (NON-ILLUSTRATED)
56	WCI 5303207391
57	WCI 3201632
58	BALLAST-LAMP (NON-ILLUSTRATED)
