RER302CD1 07 – BODY PARTS

RER302CD1 07 – BODY PARTS

Written by

in

RER302CD1 07 – BODY PARTS

Products

PositionProduct
1WCI 3017576
2WCI 08012541
3INSULATION, WRAP
4INSULATION, BACK
5AWCI 08012530
5END PANEL, RH, ALMOND
6WCI 3017535
7WCI 3017394
8WCI 3017481
8AWCI 3017482
9CHANNEL, OV. SUPT.
10LEG
11CHANNEL-OVEN SUPT
12WCI 3017633
13ARAIL, DRAWER LH
13WCI 08015746
14SPACER, RAIL
15GUIDE
16BUMPER
17BRACKET THERM. BULB
185304409888 Frigidaire Oven Terminal Block with Hardware
19WCI 08012542
20GUSSET, BACKGRD (2)
21WCI K1325538
23316067902 Frigidaire Oven Rack
24WCI K1303482
25WCI K1303481
26COVER – WIRE
27STRAP-GROUND
28WCI 3051784
