RF3010XVW4 01 – EXTERNAL, LIT/OPTIONALadmin2025-04-26T12:54:22+00:00RF3010XVW4 01 – EXTERNAL, LIT/OPTIONAL
Products
| Position | Product |
|---|
| Instuctions, Installation |
| WPL LIT677973 |
| WPL LIT313358 |
| Guide, Use & Care |
| 1 | Panel, Side (2) (White) |
| 2 | Frame, Front |
| 2 | WP308685 Whirlpool Microwave Screw |
| 3 | Rail, Base (2) |
| 4 | Base, Front |
| 5 | Support, Main (2) |
| 6 | Support, Rear (2) |
| 6 | Screw |
| 7 | Mounting Plate |
| 9 | Main Back |
| 10 | Burner Box |
| 11 | Retainer Lower |
| 12 | Screw |
| 12 | Hinge, Door (2) |
| 13 | Seal, Door (2) (Side) |
| 14 | Seal, Door (Top) |
| 15 | Bumper, Cooktop (2) |
| 21 | Leg, Leveler (4) |
| 22 | Nut (4) |
| 23 | Safe Edge |
| 24 | Tube, Vent |
| 25 | WP8203546 Whirlpool Terminal Block |
| 26 | Channel, Wire |
| 27 | Ignitor (L.H.) |
| 28 | Wire Shield |
| 29 | Cover, Rear |
| 30 | Shield, Wire |
| 31 | Anti-Tip Kit |
| 32 | Shield, Insulation |
| 34 | Stud Screw (2) |
| 34 | Locator stud (2) |
| 35 | WP72107 Whirlpool Touchup |
| 35 | FOIL, ALUMINUM OVEN (18`` X 25 ) |
| 35 | Disc, Thermo |
| 35 | W10355051 Whirlpool Cooktop Cleaner Affresh (10 Oz) |
| 35 | 72017 Whirlpool Appliance Touch-Up Paint White |
