RF310BXYW0 05 – DOOR AND DRAWER, LIT/OPTIONAL

Products

Position	Product
	WPL LIT3150285
	Wire (14 Ga. 150 c Green)
	Wire (14 Ga. 150 c Brown)
	Wire (14 Ga. 150 c Blue)
	242831 Whirlpool Oven Wire
	Paint, Spray 13 Oz. (Avocado)
	paint, spray 13 oz. (coffee)
	Paint, Touch-Up 1/2 Oz. (Coffee)
	72109 Whirlpool Dacor Avocado Touch-Up Paint
	285006 Whirlpool Spray
	Wire (14 Ga. 150 c Orange)
	Wire (14 Ga. 150 c Yellow)
	Wiring Diagram
	WPL LIT3147395
	WPL LIT884994
	Grease
	8212471 Whirlpool Oven Paint
	Leveler (Thinner) (2oz.)
	1
	Wire (14 Ga. 200 c Brown)
	18 Ga. 80~c Rating (Red)
	Wire, 25“ Roll (White 14 GA.)
	Wire, 25` Roll (Red 14 Ga.)
	Wire, 25` Roll (Black 14 Ga.)
	Paint, Spray (13 Oz.) (Platinum)
	Toast
	Golden Harvest (Uncut)
	Golden Harvest
	72113 Whirlpool Touch-Up Paint
	799344 Whirlpool Refrigerator Paint
	72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
	Almond (Uncut)
	Enamal, Toast (1 Qt. Uncut)
	Platinum (Uncut)
	WPL 72112
	FOIL, ALUMINUM OVEN (18“ X 25 )
	WPW10208653 Whirlpool Insulation
	350930 Whirlpool White Spray Paint
	WPL 799832
	511873 Whirlpool Refrigerator Paint
	350942 Whirlpool Spray Paint
	350956 Whirlpool Spray Assembly
	72017 Whirlpool Appliance Touch-Up Paint White
	WP72107 Whirlpool Touchup
1	Liner, Door
1	Back Splash (Screw (4) 10AB x 1/2“)
3	Panel, Door (Black Glass)
4	Frame, Door
4	WP355515 Whirlpool Screw
5	Top, Door (Black Model)
7	Clip, Mtg (2)
8	Handle, Oven Door
11	Drawer, Utility
12	Protector, Drawer (2)
13	Glide, Rear (2)
14	WP488787 Whirlpool Refrigerator Screw
14	Panel, Drawer (Almond)
14	Panel, Drawer (White)
15	Handle, Snap-In (White)
15	Handle, Snap-In (Almond)
16	Bracket, Mounting (2)
17	Rail L.H. (Includes Illus. 3)
17	Rail R.H. (Includes Illus. 3)
18	Screw, 10A x 1/2 (2) (Black)
18	Glide, Front (2)
